| Video Output Mode |
HD-TVI / AHD / CVI / 960H 4 in 1 Composite BNC Output |
Camera |
| Image Sensor Size |
1/2.9" 1080P Sony 2MP HD SONY Sensor |
| Image Sensor + Processor |
IMX307 + NVP2441H |
| Image Resolution |
2M:1920*1080 |
| Effective pixels |
2M:1920*1080 |
| TV System |
PAL/NTSC |
| Electronic Shutter |
1/25s ~ 1/50,000s,1/30s ~ 1/60,000s |
| S/N Ratio |
≥52dB |
| Scanning System |
Progressive Scan |
| Lens |
| Focus Length |
2.8-12mm |
| Focus Control |
Motorized |
| Lens Type |
Varifocal |
| Pixels |
3M Pixels |
| Auto Iris Support |
NO |
| Night Vision |
| Infrared LED |
￠5x 42 pcs |
| Infrared Distance |
35M |
| IR Status |
Under 10 Lux by CDS |
| IR Power On |
CDS Auto Control |
| Camera Feature |
| Starlight |
YES |
| Day/Night |
YES |
| OSD Menu Language |
YES |
| White Banlance |
Auto |
| Gain Control |
YES |
| Noise Reduction |
2D/3D-DNR |
| Picture Adjustment |
YES |
| WDR |
YES |
| OSD Cable |
Optional |
| UTC |
YES |
| DIP Switch |
Optional |
| General |
| Housing |
Metal & IP66 |
| Bracket |
NO |
| Dual Voltage |
NO |
| IR Cut Filter |
YES |
| Heater |
NO |
| Audio |
/ |
| Operation Temperature |
-10℃ ~ +50℃ RH95% Max |
| Storage Temperature |
-10℃ ~ +50℃ RH95% Max |
| Power Source |
DC12V±10%,600mA & AC24V/300mA |
| Dimension |
160(H) x 95(W) x 100(H)mm |
| Weight |
Approx 1500g |
