Camera |
| Image Sensor Size |
1/2.8" SONY Starlight CMOS Sensor (IMX307) |
| Image Sensor + Processor |
GC2033 + FH8538 |
IMX307 + NVP2441 |
| Resolution |
2M 1080P |
| Effective pixels |
1945(H)*1097(V) |
| Compression |
H.264/H.264+/H.265/H.265+/JPEG/AVI /MJPEG |
| TV System |
PAL/NTSC |
| Electronic Shutter |
Auto: 1/25s ~ 1/50,000s,1/30s ~ 1/60,000s |
| Minimun Illumination |
0.005 Lux |
| S/N Ratio |
≥52dB |
| Scanning System |
Progressive Scan |
| Video Output |
Network |
| Lens |
| Focus Length |
2.8-12mm |
| Focus Control |
Manual |
| Lens Type |
Varifocal |
| Pixels |
3M Pixels |
| Auto Iris Support |
NO |
| Night Vision |
| Infrared LED |
14μx 24 pcs |
| Infrared Distance |
30M |
| IR Status |
Under 10 Lux by CDS |
| IR Power On |
CDS Auto Control |
| NetWork |
| Ethernet |
RJ-45(10/100Base-T) |
| Wireless |
/ |
| Protocol |
TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,NTP,SMTP |
| ONVIF |
Support ONVIF 2.4 |
| P2P |
YES,Support QR Code |
| POE |
Optional,Support IEEE 802.3af |
| Video Delay |
0.3S(Within the Lan) |
| Main Stream 1 |
2048*1536 @15fps |
| Main Stream 2 |
1920*1080 @30fps |
| Main Stream 3 |
1280*720 @30fps |
| Sub Stream 1 |
720*480@15fps / 720*480@30fps |
| Sub Stream 2 |
/ |
| Sub Stream 3 |
/ |
| Tri Stream |
352*288@15fps / 352*288@30fps |
| IE Brower |
IE8-11, Google Chrome (lower than Ver44), Firefox (lower than Ver53) |
| Smart Phone |
iPhone, iPad, Android, Android Pad |
| Camera Feature |
| Day/Night |
Color/B&W (IR-CUT ) |
| Intelligence Function |
/ |
| Image Config |
Saturation/Brightness/Contrast /Sharpness, Mirror, 3D NR , White Balance, FLK(Flicker Control), Video Tampering |
| Starlight |
/ |
| Corridor Pattern |
Support |
| Defog Mode |
Support |
| ROI |
Support |
| BLC |
Support |
| HDR |
/ |
| WDR |
Support |
| Motion Detection |
Support |
| Privacy Masking |
3 Rectangular Zone |
| Recording Mode |
NVR/CMS/Web |
| Language |
Chinese Simplified, Chinese Traditional, English, Bulgarian, Polish, Farsi, German, Russian, French, Korean, Portuguese, Japanese, Turkish, Spanish, Hebrew, Italian,Nederlands |
| Interface |
| Audio |
Optional |
| Alarm |
/ |
| RS485 |
/ |
| General |
| Housing |
Metal & IP66 |
| Anti-cut Bracket |
Optional Wall Bracket |
| Dual Voltage |
NO |
| IR Cut Filter |
YES |
| Operation Temperature |
-10℃ ~ +50℃ RH95% Max |
| Storage Temperature |
-10℃ ~ +50℃ RH95% Max |
| Power Source |
DC12V±10%,500mA |
| Dimension |
120(￠) x 93(H)mm |
| Weight |
800g |
